EBOX - Electric Bike Off-road Motocross
Sometimes we just want to get loose, run for the hills and escape the bullshit, preferably at high-speed. For that we designed EBOX2.
Not content with the performance from the over-boosted 1.6 kw EBOX1, we decided to tweak the chassis and install an over-boosted 2 kw rated powertrain that peaks at over 3 kw! (As tested and reviewed by Surronster on YouTube). These modifications catapult the EBOX2 into electric pit bike class leading territory.
Featuring extended upside-down forks and 14/12 wheels, the chassis is now suitable for slightly larger (or crazier) riders. **We recommend considering some BMX style bars or pro taper minibike bars if you are a taller rider.
Created by our engineers and designers to be lightweight, powerful and outperform any other bike in its class on the market.
EBOX2 features a 2 KW lithium battery / brushless motor combination that packs an astonishing punch. EBOX2 can be controlled to perfection, dialled down for entry level riding, and turned up when you are ready to clear those doubles or pop the front wheel up for some combo practice.
Need more?. As proven by Surronster, this bike can be tuned to release even more power from the stock powertrain with a simple controller upgrade. (please note this upgrade is not currently warranty approved).
SPECS
Frame type | Double Cradle |
---|---|
Front wheel size | 14" |
Rear wheel size | 12" |
Front brake | Hydraulic Disc |
Front disc | 180mm |
Rear brake | Hydraulic Disc |
Rear disc | 180mm |
Front tire | 14" x 2.27" |
Rear tire | 12" x 3" |
Chain | 219H |
Gearing | Front 10T, Rear 70T |
Max load | 85kg |
Fork type | USD |
Shock type | Mono shock |
Handlebar | Alloy |
Motor voltage | 60V |
Peak power | 2.0kW (2.6hp) |
Max RPM | 4,400 |
Battery | 60V 18.2Ah Lithium |
Controller output | 42A |
Charger | AC 110-240V, Output: 67.2V, 3A |
Tech
Charge time | 5-6 hours |
---|---|
Range per charge | 35-40 Km |
Top speed | 52 Km/h |
External adjustability | Top speed, Acceleration |
Frame construction | High strength steel, powder coated, removable subframe, swing arm mounted motor, non linkage suspension |
Wheelbase | 945mm |
Ground clearance | 275mm |
Seat height | 66cm |
Weight | 42.5kg |
